Features & Benefits :
- Realizing high graphics with high image quality and definition
- Adaptable to work requiring quick delivery by a high printing speed
- XY slitter capable of reducing post-process work by X-axis & Y-axis sheet-fed cut
- Evolution of Usability: Media Changer, V-shape cut function, New maintenance mechanism
- New conveyance mechanism ensures reliable long hour print operation
- Mimaki Remote Access (MRA) enables wireless printer operations
Compatibility :
Inks
- SS21
- SS22
- BS4
Applications :
- Sign & Displays
- Window Graphics
- Banners
- Posters
- POP
- Vehicale Wrapping
- Wallpaper
- Cutting sheet stickers
- Labels & Decals
- POS Displays
| CJV330-130 | CJV330-160 | ||
|---|---|---|---|
| Print head | On-demand piezo head (2 staggered layout) | ||
| Print resolution | 600dpi, 800dpi, 900dpi, 1200dpi | ||
| Print gap | By manual 3 levels (2.0/2.5/3.0 mm) | ||
| Ink | Type/Color | Eco-solvent ink SS21 (C, M, Y, K, Lc, Lm, Lk, Or, W) SS22 (C, M, Y, K, Lc, Lm, Lk, Or, W) BS4 (C, M, Y, K) | |
| Capacity | SS21: 2L ink pack (500ml ink pack only for White ink) SS22: 1L ink pack (500ml ink pack only for White ink) BS4: 2L ink pack | ||
| Ink circulation | Circulation in damper MCTv2 | ||
| Maximum print width | 1,360mm (53.5") | 1,610mm (63.4") | |
| Media | Maximum width | 1,370mm (53.9") | 1,620mm (63.8") |
| Thickness | 1 mm or lower | ||
| Roll diameter | φ250 mm or less | ||
| Mountable no. | Max. Three rolls | ||
| Roll weight | One roll：Max. 45 kg (99.2 lb) or less Three rolls：Total 90 kg (198.4 lb) or less | ||
| Roll inside diameter | 2 inch / 3 inch | ||
| Media cutting | Auto cutting by cutter of head unit *1 | ||
| Cutting function | Cutting speed | Max. 300 mm/s | |
| Acceleration | Max. 0.5G | ||
| Cutting pressure | 10 - 450 gf | ||
| Cutter response times | 10 times/sec | ||
| Repeatability | ±0.2 mm (Excluding shrinkage / expansion caused by the film temperature) | ||
| Interface | Ethernet 1000 BASE-T (Recommended) / USB2.0 Hi-speed | ||
| Certifications | VCCI class A, FCC class A, ETL IEC 62368-1, CE Marking (EMC, Low voltage, Machinery directive, and RoHS), CB, REACH, Energy Star, RCM, KC, UKCA | ||
| Power supply | Main unit：(Single phase AC100-120/200-240V±10％, 50/60Hz±1Hz) ×2 | ||
| Power consumption | Max. 1,440 W or less x 2 / Min. 4.5 W or less (Sleep mode) | ||
| Operational environment | Temperature: 20–30 °C (68–86 °F) Humidity: 35–65% Rh (Non condensing) Recommended temperature: 20–25 °C (68–77 °F) Dust level: General office level | ||
| Dimensions (W×D×H) | 2,920 × 1,215 × 1,305 mm (115.0 x 47.8 x 51.4") | 3,170 × 1,215 × 1,305 mm (124.8 x 47.8 x 51.4") | |
| Weight | 363 kg (800.3 lb) | 373 kg (822.3 lb) |
*1 Cut shape can be V-shaped cut or straight cut.
Ink set
| SS21 ［C,M,Y,K,Lc,Lm,Lk,Or,W］ | C M Y K |
|---|---|
| C M Y K Lc Lm Lk Or | |
| C M Y K Lc Lm W | |
| SS22 ［C,M,Y,K,Lc,Lm,Lk,Or,W］ | C M Y K |
| C M Y K Lc Lm Lk Or | |
| C M Y K Lc Lm W | |
| BS4 ［C,M,Y,K］ | C M Y K |
